Triumph Street Twin User Manual

Specifications - Thruxton RS
186
Fuel Thruxton RS
Type 95 RON unleaded
Tank Capacity 14.0 litres
Ignition Thruxton RS
Ignition System Digital inductive
Spark Plug NGK LMAR8A-9
Spark Plug Gap 0.9 mm +0.0/-0.1 mm
Transmission Thruxton RS
Transmission Type 6 speed, constant mesh
Clutch Type Wet, multiplate
Final Drive Chain EK 525 ZVX3, 100 link
Primary Drive Ratio 93/74 (1.26)
Gear Ratio:
1st 49/14 (3.5)
2nd 45/18 (2.5)
3rd 37/20 (1.85)
4th 37/25 (1.48)
5th 35/27 (1.3)
6th 34/29 (1.17)
Final Drive Ratio 42/16 (2.63)
Warning
Use the recommended tyres ONLY in the combinations given.
Do not mix tyres from different manufacturers or mix different specification tyres
from the same manufacturers as this may result in loss of motorcycle control and
an accident.
Approved Tyres
A list of approved tyres specific to these models is available from your authorised
Triumph dealer, or on the Internet at www. triumph. co. uk.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
