Triumph Street Twin User Manual

General Information
73
Street Scrambler Seat Removal
Note
If a passenger seat is fitted, it must be
removed before removing the rider’s
seat.
If a luggage rack is fitted, the rider’s
seat can be removed without removing
the luggage rack.
Passenger Seat Removal
cjyn
2
1
1. Passenger seat
2. Fixing
To remove the passenger seat:
• Remove the fixing securing the
passenger seat to the luggage rack
subframe.
• Lift the seat up from the back and
slide rearwards to remove it from
the motorcycle.
Rider’s Seat Removal
To remove the rider’s seat:
• Remove the passenger seat if fitted.
• Insert the ignition key into the seat
lock and turn it anticlockwise while
pressing down on the rear of the
seat. This will release the seat from
its lock.
• Lift the seat up from the back and
slide rearwards to remove it from
the motorcycle.
Street Scrambler Seat Installation
Warning
To prevent detachment of the seat
during riding, after fitting always
grasp the seat and pull firmly upwards.
If the seat is not correctly secured in
the lock, it will detach from the lock.
A loose or detached seat may cause
loss of motorcycle control and an
accident.
Rider’s Seat Installation
To install the rider’s seat:
• Engage the seat’s tongue under the
fuel tank.
• Press firmly down in the centre of
the seat to engage the lock.
• An audible click can be heard when
the seat is correctly engaged in the
lock.
• Grasp the seat and make sure it is
securely retained.

Triumph Street Twin Specifications

General

Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Displacement	900 cc
Bore x Stroke	84.6 x 80 mm
Compression Ratio	11.0:1
Max Torque	80 Nm @ 3, 800 rpm
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Gearbox	5-speed
Frame	Tubular steel, twin cradle
Front Tire	100/90-18
Rear Tire	150/70 R17
Dry Weight	198 kg
Wet Weight	216 kg
Fuel Consumption	4.1 l/100 km
CO2 Emissions	93 g/km
Max Power	65 PS (64 bhp) @ 7, 500 rpm
Exhaust	Brushed 2 into 2 exhaust system with twin brushed silencers
Front Suspension	41mm forks
Rear Suspension	Twin shocks with adjustable preload
Front Brakes	Single 310mm disc, Nissin 2-piston floating caliper
Rear Brakes	Single 255mm disc, Nissin 2-piston floating caliper
Front Wheel	Cast aluminium alloy, 18 x 2.75 in
Rear Wheel	Cast aluminium alloy, 17 x 4.25 in
Seat Height	765 mm
Fuel Tank Capacity	12L
Width (Handlebars)	780 mm
Wheelbase	1450 mm
Rake	25.1 °
Trail	102.4 mm
