Triumph Tiger 900 Rally Pro 2020 User Manual

Parts Identification
18
Parts Identification
Tiger 850 Sport, Tiger 900 GT and Tiger 900 GT Pro
2 3
4 5
17 16 15
13
1218
1
14
1 07 86 9
11
1. Headlight
2. Front turn signal
3. Electrical accessory socket (front)
4. Fuel tank and fuel filler cap
5. Tool kit (under the rider seat on
Tiger 900 GT and Tiger 900 GT Pro)
6. Battery and fuse boxes (under the rider
seat)
7. Seat lock
8. Electrical accessory socket (rear if
equipped)
9. USB socket (under the passenger seat) (if
equipped)
10. Heated rear seat switch (if equipped)
11. Tool kit (under the passenger seat on
Tiger 850 Sport only)
12. Rear wheel adjuster
13. Drive chain
14. Center stand (if equipped)
15. Side stand
16. Gear shift pedal
1 7. Front brake caliper
18. Front brake disc
