Triumph Tiger Handbook

Foreword
4
Table of Contents
This handbook contains a number of different sections. The table of contents below will help
you find the beginning of each section where, in the case of the major sections, a further table
of contents will help you find the specific subject required.
Foreword . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Parts Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Serial Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
How to Ride the Motorcycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Accessories, Loading and Passengers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Maintenance and Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 3

Triumph Tiger Specifications

General

Displacement	888 cc
Compression Ratio	11.27:1
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Gearbox	6-speed
Swingarm	Twin-sided, cast aluminium
Front Wheel	Cast aluminium, 19 x 2.5 in
Rear Wheel	Cast aluminium, 17 x 4.25 in
Front Tyre	100/90-19
Rear Tyre	150/70R17
Wet Weight	210 kg
Engine	Liquid-cooled, in-line 3-cylinder
Bore x Stroke	78.0 mm x 61.9 mm
Clutch	Wet, multi-plate
Frame	Tubular steel frame
Rear Brakes	Single 255 mm disc, ABS
Tank Capacity	20 L
Wheelbase	1, 555 mm
