VEHICLE DIMENSIONS
Dim. Description
inches
mm
Dim.
Description
inches
mm
A Wheelbase
88'00 2240
N
Seat squab to steering wheel:
B Front track:
Max.
18'50
470
Disc or \\'ire wheels
50'25
1276
Min. 14'00 355
C
Rear track:
p
Seat cushion to steering wheel 6'50 165
Disc or
Wire wheels
49.75
1264
Q
Length of luggage space behind seats:
Max.
21"50 546
D
Overall length
155-00
3937
Min. 17'00
432
DI
Overall length (1974
USA Market)
162'13
4118
R Floor to luggage platform
9'00
229
E
Overall width
58'00
1470
S
Height - floor to
top of seat squab 22'50 572
F
Height (unladen)
U.S.A. only
Soft
top - hood erect
50'00
1270
floor
to top of seat restraint
30'00 762
to
top of windscreen
46-00
1170
T
Width between wheel arches
33'50 850
Hood folded and windscreen removed
40'00 1020
U
Maximum interior height
40'50 1030
G
Seat width
19'00 483
V Maximum interior width
50'50 1282
H
Width between seats
6'00 152
W
Luggage compartment height:
1
Seat height - floor to cushion
7'50
190
Max.
13'50
343
Min.
9'50 242
K
Seat
de!'th
16'50
419
X
Luggage compartment depth 20'00 508
L
Headroom from seat cushion
36-00
915
Y
Luggage compartment width:
M
Seat squab to clutch pedal:
Max.
46'00 1170
Max.
40'50
1030
Min.
44-00 1117
Min.
36-00
915
Z
Luggage compartment effective opening width 43'00 1091
~
