Trojan Flooded User Manual

9
USER’S GUIDE
9
Gel
LT UT
DT AP
Images shown reect correct hardware placement. *Hardware not supplied by Trojan Battery Company.
Washer*
Nut - Torque to 95-105 in-lbs (11-12 Nm)
Nut - Torque to 95-105 in-lbs (11-12 Nm)
Nut - Torque to 95-105 in-lbs (11-12 Nm)
Cable Lug
Cable Lug
Terminal
Washer*
Washer*
Cable Lug
Terminal
AP Connector
Torque to 50-70 in-lbs (6-8 Nm)
Terminal
AP Connector
Torque to 50-70 in-lbs (6-8 Nm)
Bolt
Bolt
AP Connector
Torque to 50-70 in-lbs (6-8 Nm)
Stud Terminal
AP Terminal
Washer
Cable Lug
AP Connector
Torque to 44-62 in-lbs (5-7 Nm)
Terminal
