3. PARTS LIST 4. HARDWARE LIST
No. Description Q’ty
1042-01 Right Upright 1
1042-02 Crossbar 1
1042-03 Left Upright 1
1042-04 Main frame 1
1042-05 T-front Leg (Frame) 1
1042-06 Seat 1
1042-07 Backrest Bars 2
1042-08 Backrest 1
1042-09 Swing Arm 1
1042-10 Pad Holders 2
1042-11 Foam Pads 4
1042-12 Rod 1
1042-13
Brace Bar
1
No. Description Q’ty
1042-14 Bolt (3/8” x 2-1/2”) 1
1042-15 Bolt (3/8” x 2-1/4”) 6
1042-16 Bolt (3/8” x 3/4”) 1
1042-17 Bolt (1/4” x 1-1/2”) 4
1042-18 Bolt (1/4” x 1/2”) 4
1042-19 Bolt (5/16” x 3/4” ) 2
1042-20 Nut (3/8” ) 7
1042-27 Washer (5/16”) 2
1042-22 Washer (3/8”) 14
1042-23 Washer (1/4”) 8
1042-24 Round Cap (1”) 2
1042-25 Round Cap (3/4”) 6
1042-26 Square Cap (1-1/2”) 4
1042-27 Square Cap (1-1/4”) 4
1042-28 Square Cap (1”) 2
NOTE :
The described parts are all you need to assemble this machine.
Before starting assembly, please check the hardware packing to make sure they are included.
