13. PARTS LIST
NOTE :
The described parts are all you need to assemble this machine.
Before starting assembly, please check the hardware packing to make sure they are included.
No. Description Q’ty
1143-1 Main Stand 1
1143-2 Struts For Pedals 2
1143-3 Cylinder 2
1143-4 Large Thrust Unit. 1
1143-5 Small Thrust Unit 1
1143-6 Thick Washer 1
1143-7 Bolt (M8 x 01.25 x 25mm) 3
1143-8 Thrust Unit 1 2
1143-9 Large Washer 4
1143-10 Thrust Unit 2 4
1143-11 Anti-slip Washer 2
1143-12 Thrust Unit 3 2
1143-13 Washer 4
1143-14 Thrust Unit 4 4
1143-15 Suspension Arm 2
1143-16 Magnets 1
1143-17 Plastic Tubing 2
1143-18 Washer 1 2
1143-19 Screw (M8 x ø1.25 x10mm) 4
1143-20 Dished Washer 2
No. Description Qty
1143-21 Thrust Unit (M8) 4
1143-22 Thrust Unit (M14.8) 8
1143-23 Cylinder Mounting 2
1143-24 Lower Cover 1
1143-25 Pedal Cover
1143-26 Monitor 1
1143-27 Front Supporting Leg 2
1143-28 Bolt (M8 x 01.25 x 80mm) 2
1143-29 Narrow Washer (M8) 10
1143-30 Nut (M8) 6
1143-31 Bolt (M8 x ø1.25 x 40mm) 2
1143-32 Screw (M8 x ø1.25 x 40mm) 2
1143-33 Screw (M6 x 16mm) 6
1143-34 Screw (M4 x10mm) 2
1143-35 Screw (M4 x 10-10C) 1
1143-36 Damping Block 2
1143-37 Resistance Band 2
1143-38 Rear Supporting Leg 2
1143-39 Plastic Monitor Housing 1
1143-40 Thrust Unit 5 4
To Next Page
