Trotec BS06 User Manual

4 EN
digital sound level meter BS06
Display
9
8
10
No. Designation
8 Minimum value indication
9 Indication of the measured value in dB(A)
10 Maximum value indication
Technical data
Parameter Value
Model BS06
Weight 140g
Dimensions
(lengthx widthx height)
132mmx 56mmx 33mm
Measuring range 30 to 130dB(A)
(31.5Hz to 8kHz)
Accuracy ± 3.5dB (at 1kHz and 94dB)
Measuring range resolution 0.1 dB
Time weighting 125ms
Microphone 1/2inch electret condenser
microphone
Operating temperature 0to 40°C with 10to 75%RH
Operating altitude max. 2000m
Storage temperature -10 to 60°C
Power supply 1x Alkaline 9V battery
battery life: approx. 5000 to
8000measurements
Automatic switch-off after approx. 15minutes
Scope of delivery
• 1x Digital sound level meter BS06
• 1 x 9V battery
• 1 x Wind shield for microphone
• 1x Manual
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device use a suitable bag to protect it from
external influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• with a cover to protect it from invasive dust if necessary
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the batteries from the device.
Operation
Inserting the battery
Note
Make sure that the surface of the device is dry and the
device is switched off.
4
13
1. Remove the cover(4) from the device by sliding it in the
direction of the arrow.
2. Use the battery clip(13) to connect the new battery with
correct polarity.
3. Slide the cover(4) back on the device.
