8 EN
wet and dry vacuum cleaner VC 1200W
Proceed as follows to remove the hose(1):
1. When connected, turn the end of the detergent pipe(2) in
counter-clockwise direction and remove the detergent pipe
from the fitting(22) (I.).
2. Turn the hose(1) in counter-clockwise direction and,
depending on the application, remove it from the air intake
opening(6) or air outlet opening(3) (II.).
Utilising suction pipes
To extend the reach, you can connect one or two suction pipes
to the hose.
1. Attach the suction pipe(12) to the suction end of the
hose(1) with the connection side (I.).
2. Press the locking button(24) on the suction pipe.
3. Insert the end of the detergent pipe(2) into the fitting and
let go of the locking button(24) (II.).
4. If required, attach the second suction pipe(12) to the
suction end of the first suction pipe(12) with the
connection side (III.).
5. To do so, press the locking button(24) on the lower
suction pipe and plug the two pipes together so that they
interlock (III.)
6. Let go of the locking button(24) (IV.).
Proceed as follows to remove the suction pipes:
1. Press the locking button(24) on the lower suction pipe (I.)
and draw the suction pipes apart (II.).
2. Press the locking button(24) on the upper suction pipe and
remove the detergent pipe(2) from the fitting (III.).
3. Remove the upper suction pipe(12) from the suction end
of the hose(1) (IV.).
