Trotter moov8 - Maintenance; Technical Parameter

XIII. Maintenance
1. Storage
Do not place your Trotter MAGWheel in extreme damp/humidity, heat or cold. It is suggested to drain the battery to 50%-60% if stored
for long periods.
2. Routine Checks
Every so often – especially after hard riding – check the rubber sensor pads, plastic trim pieces, bottom plates and axle mounts for dirt,
debris and loose screws. Make sure you are using the proper size bits to prevent stripping.
3. Tire Replacement
The Trotter MAGWheel uses a top-grade tubeless tire. When the tire needs to be maintained or changed due to normal wear or damage,
disconnect the power supply first; remove all 8 large allen screws from each side of the tire/motor; separate the motor and main control
panel connectors and take out the motor wiring harness. The nose trim piece will need to be removed as well. During the process, please
pay attention to the connecting wiring harness in the pedal and do not pull hard.
Note: After completing the maintenance, the power supply terminals may spark when being reconnected; this is a normal
phenomenon and you needn't be scared.
XIV. Technical Parameter
Item Specifications Parameter contents Instruction
Performance
Maximum speed
20km/h
Driving mileage
Up to 25km
Depending on the rider's weight, road condition and the environmental temperature
Maximum climbing angle
About 20°
Power of battery
4.4 ah / 5.2 ah / 10.5 ah (optional)
The fender boasts the function of balance
Temperature suitable for riding
Minus 10 'C -40 'C
Storage temperature
Minus 30 C - 70 C
Maximum load
120kg
Charger voltage
AC 220V 50-60HZ
Charging time
2 hours
Appearance and
weight
Overall dimensions
741x259x280mm
The distance between the pedal and ground
174.5mm
Tire dimensions
中 280mm (11.5inch tubeless go-kart vacuum tire)
Body weight of the vehicle
13.9kg
Protection
measures
Side tilt protection
Both are 45°on the left and right
The motor will stop rotating while exceeding 45°
Speed-limiting protection
Start when it is more than 15 km/h
The front end of the pedal rises to prevent further acceleration.
Low battery indication
The red light flickers when about 25% of the battery power is left
The buzzer beeps once every 15 seconds
Information
indication
Battery indicator
The red light starts when about 10% of the battery power is left
The front end of the pedal begins to rise
The red indicators on both sides flicker
The battery power is less than 25%
Voice reminder
Beep
Continuous beeps during the low electric quantity protection
Blew
Blew while tilting to the side
Attachment
Standard
Charger
