Trox Technik FKR-EU - Technical Data; General Data

Fire dampers
Correct use FKR-EU
1
K4 – 1.1 – 903/2017 – DE/en
Essential characteristic: fire resistance ― size [mm]: Ø 315 to Ø 800
Supporting
construction
Construction
• Metal stud wall with sheet steel insert, used as a fire wall, safety
partition wall or to provide radiation protection
• Gypsum bonded or cement bonded panel materials or fibre-
reinforced gypsum
• d≥100mm
• With or without mineral wool
• Distancetoload-bearingstructuralelements≥40mm
• Distancebetweencasings≥40mm
• Metal stud wall with sheet steel insert, used as a fire wall, safety
partition wall or to provide radiation protection
• Gypsum bonded or cement bonded panel materials or fibre-
reinforced gypsum
• d≥100mm
• With or without mineral wool
• Installation kit TQ
• Metal stud wall
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥75mm
• With or without mineral wool
• Wallthicknessincreasedtod≥98mm
• Metal stud wall
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥75mm
• With or without mineral wool
• Wallthicknessincreasedtod≥98mm
• Installation kit TQ
• Timber stud wall (also timber panel constructions and timber
frames)
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥130mm
• Distancebetweencasings≥40mm
• Distancetoload-bearingstructuralelements≥40mm
• Timber stud wall (also timber panel constructions and timber
frames)
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥130mm
• Installation kit TQ
• Timber stud wall (also timber panel constructions and timber
frames)
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥105mm
• Wallthicknessincreasedtod≥130mm
• Distancebetweencasings≥40mm
• Distancetoload-bearingstructuralelements≥40mm
• Timber stud wall (also timber panel constructions and timber
frames)
• Gypsum bonded or cement bonded panel materials, fibre-
reinforced gypsum or fire rated calcium silicate boards
• d≥105mm
• Wallthicknessincreasedtod≥130mm
• Installation kit TQ
Installation
location
in the wall
in the wall
in the wall
in the wall
in the wall
in the wall
in the wall
in the wall
Installation type
Mortar-based
installation
Dry mortarless
installation
Mortar-based
installation
Dry mortarless
installation
Mortar-based
installation
Dry mortarless
installation
Mortar-based
installation
Dry mortarless
installation
EI 90 (v
e
i↔o)S
EI 90 (v
e
i↔o)S
EI 30 (v
e
i↔o)S
EI 30 (v
e
i↔o)S
EI 90 (v
e
i↔o)S
EI 90 (v
e
i↔o)S
EI 30 (v
e
i↔o)S
EI 30 (v
e
i↔o)S
Class of
performance
(EI TT)
Lightweight
partition wall
