12 se c t i O n 5— Op e r a t i O n
Using The Hose Assembly
nozzle to redirect vacuum to the hose assembly. See Fig.
The spring loaded pin must be in the second hole of the 2.
Unhook the hose from upper and lower hose handle 3.
brackets and grasp the hose handle to guide the hose
while vacuuming yard waste such as leaves or pine needles.
If necessary, attach the hose extension to vacuum in hard
to reach places as follows:
Insert round end of hose extension into end of hose a.
assembly.
Secure strap on hose extension to pin on hose b.
assembly. See Fig. 5-5.
Using The Nozzle Vacuum
Yard waste such as leaves and pine needles can be vacuumed
up through the nozzle for shredding. After material has been
shredded by the flail blades on the impeller assembly, it will be
discharged into catcher bag. Do not attempt to shred or chip
any material other than vegetation found in a normal yard (i.e.
branches, leaves, twigs, etc.) Avoid fibrous plants such as tomato
vines until they are thoroughly dried out. Materials such as stalks
chipper chute.
nozzle to vacuum through nozzle. See Fig. 5-3.
The spring loaded pin must be in the first hole (closest to 2.
the end of the tube) of the hose adapter to operate the
nozzle vac. See Fig. 5-3.
3.
yard waste.
WARNING: Do not attempt to shred, chip, or
vacuum any material larger than specified on the
damage to the machine could result.
IMPORTANT: The flail screen is located inside the housing in
the discharge area. If the flail screen becomes clogged, remove
and clean as instructed in Maintenance & Adjustments. For best
performance, it is also important to keep the chipper blade
sharp.
Figure 5-3
Figure 5-4
Figure 5-5
