18 Section 7— Service
Remove all dirt and clean the area around the transmission
cover. See Fig. 7-3.
Figure 7-3
Transmission
Housing
Transmission
Cover
Hex Screw
5. Remove the four hex screws (⁄
transmission cover to the drive shaft and remove the cover.
See Fig. 7-3
Remove the left-side wheel. Tilt the left-side wheel shaft
into a drain pan and allow the gear oil to drain through the
top of the transmission.
7. Reinstall the wheel and reinstall the transmission cover.
8. Refill the transmission using Mobil 1®
Refill the engine with motor oil and replenish the fuel tank
with gasoline.
Reinstall the belt cover.
