WARNING:
To avoid serious personal injury, make
sure that the blower tubes are locked in place or firmly
installed.
ASSEMBLY INSTRUCTIONS
The completed blower tube should look like Figure 6.
Fig. 6
Adjusting the Throttle Grip
1. Move the throttle grip to a location on the upper blower tube
that is comfortable for you (Fig. 7).
2. Using a Torx® screwdriver, tighten the two screws at the
bottom of the throttle grip (Fig. 8).
Fig. 7
Throttle Grip
Fig. 8
Flex Tube
Hose Clamp
Elbow Tube
Upper Blower Tube
Lower Blower
Tube
Nozzle
Throttle Cables
Hose Clamp
Cruise Control
On/Off Switch
Throttle Grip
Upper Blower Tube
