REPLACEMENT PARTS – MODEL TBGC
GARDEN CULTIVATOR ADD-ON
PPN 41AJGC-C063
Reissued 8/02
1
2
3
5
6
9
10
11
8
11
10
7
Item Part
No. Description
1 791-612605 Accessory Hanger
2 791-180916 Drive Shaft Housing Assembly
3 791-613300 Flexible Drive Shaft
4 753-04078 Retainer Sleeve
5 753-04266 Guard Mounting Hardware Set
6 753-1216 Guard
7 791-180288 Bolt
8 791-147474 Gear Box Assembly
9 791-147473 Tine Fastener Assembly
10 791-182729 Tine Assembly
(Left Outer or Right Inner)
11 791-182730 Tine Assembly
(Left Inner or Right Outer)
4
9
9
5
5
