In case of 2-cycle & 4-cycle engine.
5.2mm
Blind Nut
Blind Nut (4mm)
4
165mm
Ply (25x25x3mm)
20
4
Blind Nut (4mm)
20
Ply (25x25x3mm)
TP Screw (2.3x8mm)
5
1
Engine mount (68x105mm)
Linkage Stopper
4
4
12
4
Washer(4x8mm)
Screw (4x35mm)
Spring Washer (4mm)
Nut (4mm)
1
4
Screw (4x25mm)
2
Plastic tube (2x650mm)
Securely glue together. If coming off during flights, you 'll
lose control of your airplane which leads to accidents!
2.5mm
1mm
Rudder
Tailing
edge
Cut away the rubber tube when
the epoxy glue dried.
Make sure they are in
the right position while
installing.
The front view when the engine install completion.
Drill four holes to appropriate position in the diameters
as show for engine mount.
The side view when the engine install completion.
Keep some space about 1mm width between the
vertical tailing edge and the rudder.
Assemble the rudder to the vertical tail with AB glue
33
35
36
37
7
34
Accessory list for the coming installation steps.
Make sure hinges are
mounted in the same line.
4
Pin hinge(2.5x48mm)
43mm
80mm
64mm
64mm
Securely glue together. If coming off during flights, you 'll
lose control of your airplane which leads to accidents!
Elevator
1mm
Tailing
edge
Make sure they are in
the right position while
installing.
4mm
4
Wood dowel (4x30mm)
1
Rib template (3mm ply)
4mm
Securely glue together tightky. If coming off during flights,
you 'll lose control of your airplane which leads to accidents!
2.5mm
Aplly instant type AB glue to rudder and pin hinge
Assemble the horizontal tail to fuselage as below and
take care to keep them clean.
Keep some space about 1mm width between the
elevator and horizontal tail edge.
Assemble the elevator to the horizontal tail with CA glue.
Drill two holes at the stabilizer root base on rib template
and wood dowel in them.
According to thr rib template drill holes to the tail of
fuselage as below.
27
28
29
30
31
6
32
