28
The greater the care given to the motorcycle, the
longer its service life will be and the better it will
perform. Check all the elements listed below and
keep them clean and lubricated for optimum ser-
vice:
·LEVER ARTICULATIONS
·REAR BRAKE PEDAL
·GEAR LEVER
·FOOTRESTS AND SIDE STAND
·STARTER PEDAL
·THROTTLE
·STEERING COLUMN
·DRIVE CHAIN AND SWING ARM ARTICULATIONS
·CHAIN TENSIONER
MOTORCYCLE MAINTENANCE
TORQUE Nm
Swinging arm-Chassis 40-50
Upper shock absorber fastener 40-50
Lower shock absorber fastener 40-50
Front wheel axle 40-50
Connecting rods 40-50
Handlebar 25-30
Front mudguard bridge 7-10
Muffler 10-15
Rear wheel axle 40-50
Front brake calliper fasteners 25-30
Exhaust pipe fasteners 10-15
Engine fasteners 30-35
Rear brake master cylinder fasteners 7-10
Spark plug 11
UNIÓN Nm
Ignition fasteners 7-8
Clutch fasteners 20-25
Cylinder stud fasteners 25
Reed valve fasteners 7-8
Clutch spring fasteners 3-4
Sump fasteners 7-8
Water pump cover fastener 7-8
Clutch cover fasteners 7-8
Flywheel fasteners 40
Ignition cover 7-8
Sump drain plug 12
Starter pedal bolt 12-13
Tornillo del pedal de cambio 7-8
Gear change pedal bolt 12-13
TIGHTENING TORQUES
37 - Motorcycle maintenance 38 - Pares de Apriete
/
