26
TRUE RESIDENTIAL
™
REMOVING THE DOORS
REMOVING THE DOORS
Open the door to 90 degrees. (See Image 23). Lift the door straight up and out of the hinges. (See Image 24).
To re-install, hold the door 90 degrees to the opening and align hinge posts to the hinges. Lower the door into
place.
KICK PLATE INSTALLATION
KICK PLATE
The kick plate is shipped with the unit but not attached to allow access to level the unit (See Image 25). Once
the unit is level, the kick plate attaches to the front, bottom of the unit with magnets located on the left and
right. (See Image 26).
FIGURE 23 FIGURE 24
FIGURE 25 FIGURE 26 - Magnets Installed Kick Plate
