CHAPTER 2: ASSEMBLY INSTRUCTIONS
BIKE ASSEMBLY STEPS (continued):
Step 1 & 2 Front and Rear Stabilizer Bars:
CAUTION:
• It is
recommended that at least 2 people are used to assemble the bike
• To protect the floor from damage, rest the bike frame on a large piece of cardboard packaging
• For e
ach screw (#24), install
through flat washer (#21)
• Insert Front Stabilizer into the
metal bracket
• Wheels of Front Stabilizer should
be forward, as shown (left)
• Install each screw assembly
(quantity 2) through the top of the
metal bracket, then into the Front
Stabilizer
• Tighten using the provided 6mm
hex wrench
• For e
ach screw (#24), install through
flat washer (#21)
• Insert Rear Stabilizer into the metal
bracket
• Install each screw assembly
(quantity 2) through the top of the
metal bracket, then into the Rear
Stabilizer
• Tighten using the provided 6mm hex
wrench
Wheels Forward
Truefitness.com / 800.426.6570 / 636.272.7100 10
