STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
St. Charles Industrial Center • P.O. Box 970 • O’Fallon, Missouri 63366 • (636)240-2400 • FAX (636)272-2408 • (800)325-6152 • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TS-72 TFEY01E TFEY01S TFEY01P TFEY013
TS-72
DESIGN
• True’s solid door reach-in’s are designed
with enduring quality that protects your
long term investment.
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self-contained,
capillary tube system using
environmentally friendly (CFC free) 134A
refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor
and large condenser; maintains 33°F to
38°F (.5°C to 3.3°C) for the best in food
preservation.
• Sealed, cast iron, self-lubricating
evaporator fan motors and larger fan
blades give True reach-in’s a more
effi cient, low velocity, high volume
airfl ow design. This unique design
ensures faster temperature recovery and
shorter run times in the busiest of food
service environments.
• Bottom mounted condensing unit
positioned for easy maintenance.
Compressor runs in coolest and most
grease free area of the kitchen. Allows
for storage area on top of unit.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors,
front and sides. Matching aluminum
back.
• Interior - 300 series stainless steel liner
and fl oor.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• Cabinet mounted on a welded, heavy
duty galvanized frame rail. Rail dipped
in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fi tted with 4" (102 mm)
diameter stem castors - locks provided
on front set.
DOORS
• 300 series stainless steel exterior and
door liner. Doors extend full width of
cabinet shell. Door locks standard.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Lifetime guaranteed recessed door
handles standard. Each door fi tted with
12" (305 mm) long recessed handle
that is foamed in-place with a sheet
metal interlock to ensure permanent
attachment.
• Magnetic door gaskets of one piece
construction, removable without tools
for ease of cleaning.
SHELVING
• Three (3) adjustable, heavy duty PVC
coated wire shelves. 24
1
/8"L x 22
3
/8"D
(613 mm x 591 mm). Four (4) chrome
plated shelf clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on
1
/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting - safety
shielded. Lights activated by rocker
switch mounted above doors.
MODEL FEATURES
• Exterior mounted temperature monitor.
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• NSF-7 compliant for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for fi nal connection to a 115/60/1
phase - 15 amp dedicated outlet. Cord
and plug set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒ 230 - 240V / 50 Hz.
❒ 6"(153 mm) standard legs.
❒ 6" (153 mm) seismic/fl anged legs.
❒ Alternate door hinging (factory
installed).
❒ Additional shelves.
❒ Half door bun tray racks. Holds up to
eleven 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately).
❒ Full door bun rack. Holds up to twenty-
two 18"L x 26"D (458 mm x 661 mm)
sheet pans (sold separately).
❒ Remote cabinets (condensing unit
supplied by others), consult factory
technical service department for BTU
information.
115/60/1
NEMA-5-15R
ELEVATION
PLAN VIEW
TS Series:
Reach-In All Stainless Steel
Solid Door Refrigerator
79
1
/16
"
(2009 mm)
84
1
/16
"
(2136 mm)
78
1
/8
"
(1985 mm)
5
"
(127 mm)
24
15
/32
"
(622 mm)
53
31
/32
"
(1371 mm)
29
1
/2
"
(750 mm)
