undercounter and worktop freezers
www
.truemfg.com
SHELVING INSTALLATION / OPERATION
SHELF INSTALLATION:
A. Hook shelf clips onto shelf standards.
B. Position all four shelf clips equal in distance from the floor for
flat shelves.
C. Shelves are oriented so that cross support bars are facing
down.
D. Place shelves on shelf clips making sure all corners are seated
properly.
Shelf
Clip
Shelf
Shelf
Pillaster
(I-beam)
Shelf
WARNING!
Do not use pliers or any crimping tools when installing shelf clips.
Altering shelf clips in any way can lead to shelving instability.
STANDARD ACCESSORIES
SETUP
