HARDWARE
A. Ceiling Bracket
B. Mounting Slot
C. Mounting Screws
D. Cable Inputs
E. System Status Indicator (SSI)
The APOGEE logo color will change according to
status
F. System Connection Indicator (SCI)
The SCI lightbar will change color upon error
G. Center Camera
H. Offset Camera
I. APOGEE Laser Indicator
Projects ball placement pattern on ground
J. Microphone
K. Infrared Lighting System
These are internal, with the light passing
through the acrylic faceplate.
