Truma Climaster - Accessories

10
Accessories
1. Replacement return air filter
part no. 40040-61900
Fig. 18
2. Return air grille, (for return
air from the living area to
the installation area)
part no. 40040-29200
190
350
Fig. 19
3. Extension cable for the
control panel 5 m
part no. 40040-54400
Fig. 20
4. Cold air duct KR 65,
dia 65 mm (per metre)
part no. 40200-01
5. Clip US, (to fix the air
duct to the wall)
part no. 40241-01
Fig. 21
6. Cold air channel,
(without connector muff)
part no. 40040-32200
7. Connector muff AZ
(to connect the cold air
duct KR 65 to the
cold air channel)
part no. 40040-24100
242
80
max. 1890
35
Fig. 22
8. Elbow BG,
(for narrow bends in the
air duct)
part no. 39010-76400
9. T-pipe
part no. 40151-01
10. Y-pipe
part no. 40191-01
11. Straight connector UM
part no. 40161-01
Fig. 23
12. Air outlet EN, black
part no. 40171-05
Fig. 24
13. Nut EM, agate grey
part no. 40181-01
Fig. 25
