truMedic PL-009 - Page 28

Table 1: Relation between the hardware buttons and software-controlled outputs of PL-009
Left ON/OFF
Right ON/OFF
MASSAGE
BEAT
KNEAD
BACK
SHOULDER
JOINT
HAND-FOOT
SOLE
REPEAT
SPEED +
SPEED -
HARDWARE BUTTON
Using the left potentiometer switch to turn on or off the left output of the device
Using the right potentiometer switch to turn on or off the right output of the device
Simulating the activity of Massage, as shown in Figure 1
Simulating the activity of Beat, as shown in Figure 2
Simulating the activity of Knead, as shown in Figure 3
The BEAT output
The repeat of the last output selected
The increase of the output intensity
The decrease of the output intensity
An output mixture of the BEAT output for 30 second, the KNEAD output for 30 second, the
MASSAGE output for 30 second, the BEAT plus KNEAD outputs for 30 second, and the
MASSAGE output for 30 second
An output mixture of the MASSAGE output for 30 second, the MASSAGE plus BEAT outputs
for 30 second, the BEAT output for 30 second, the KNEAD output for 30 second, the BEAT
output for 30 second, and the KNEAD output for 30 second
An output mixture of the BEAT output for 60 second, the KNEAD output for 30 second, the
MASSAGE plus BEAT outputs for 30 second, the MAASAGE output for 30 second, and the
BEAT output for 30 second
An output mixture of the MASSAGE plus BEAT outputs for 30 second, the BEAT output for
30 second, the MASSAGE output for 30 second, the BEAT output for 60 second, and the
KNEAD output for 30 second
SOFTWARE OUTPUT
