Range Resolution Accuracy
-40 ºC - 150 ºC 1 ºC (1,0% + 4 dgts)
150 ºC - 1 370 ºC (1,5% + 15 dgts)
-40 ºF - 320 ºF 1 ºF (1,0% + 4 dgts)
320 ºF - 1 999 ºF (1,5% + 15 dgts)
Overload Protection: 500 mA / 250 V fuse (range without fuse, 10 A).
Voltage drop measurement: 200 mV
RESISTANCE
Open Circuit Maximum Voltage: 3 V
Overload Protection: 15 seconds maximum 220 V RMS
TEMPERATURE (WITH THERMOCOUPLE TYPE K)
4. OPERATION INSTRUCTIONS
MEASURING VOLTAGE DC AND AC
1. Connect the red test probe to the “VΩmA” connector; the black test
probe to the “COM” connector.
2. Set the RANGE switch into the desired VOLTAGE range. If the voltage
to be measured is unknown beforehand, set the switch in the higher range
and reduce until getting a satisfactory reading.
3. Connect the test probes to the device or circuit to be measured.
4. Turn on the power of the device or circuit to be measured. Voltage
value will shoe in the digital screen together with the voltage polarity.
Range Resolution Accuracy
200 Ω 0,1 Ω (1.0 % of rdg + 10 dgts)
2 kΩ 1 Ω
20 kΩ 10 Ω (1.0 % of rdg + 4 dgts)
200 kΩ 100 Ω
2 MΩ 1 kΩ
