WARNING!
To avoid possible electric shock or personal injury, and to avoid possible
damage to the Digital multimeter or to the equipment under test, please
follow the following rules:
Before using the Digital multimeter inspect the case. Do not use the
Digital multimeter if it is damaged or the case or part of the case is
removed. Look for cracks or missing plastic. Pay attention to the
insulation around the connectors.
Inspect the test leads for damaged insulation or exposed metal.
Check the test leads for continuity.
Do not apply more than the rated voltage, as marked on the Digital
multimeter, between the terminals or between any terminal and
grounding.
The rotary switch should be placed in the right position and no
changeover of range shall be made during measurement is
conducted to prevent damaging the Digital multimeter.
When the Digital multimeter working at an effective voltage over 60
V in DC or 30 V rms in AC, special care should be taken for there is
danger of electric shock.
Use the proper terminals, function, and range for your
measurements.
Do not use or store the Digital multimeter in an environment of high
temperature, humidity, explosive, flammable and strong magnetic
fields. The performance of the Digital multimeter may deteriorate
after dampened.
When using the test leads, keep your fingers behind the finger
guards.
Disconnect circuit power and discharge all high-voltage capacitors
before testing resistance, continuity, diodes or hFE.
Replace the battery as soon as the battery indicator “ ” appears.
With a low battery, the Digital multimeter might produce false
readings that can lead to electric shock and personal injury.
Remove the connection between the testing leads and the circuit
being tested, and turn the Digital multimeter power off before
opening the Digital multimeter case.
When servicing the Digital multimeter, use only the same model
number or identical electrical specifications replacement parts.
The internal circuit of the Digital multimeter shall not be altered at will
to avoid damaging it or having an accident.
Soft cloth and mild detergent should be used to clean the surface of the
Digital multimeter when servicing. No abrasive and solvent should be
used to prevent the surface of the Digital multimeter from corrosion,
damage and accident.
The Digital multimeter is suitable for indoor use.
Turn the Digital multimeter power off and take out the battery when
not in use for a long time. Constantly check the battery as it may leak
when it has been used for some time, replace the battery as soon as
leaking appears. A leaking battery will damage the Digital multimeter.
1. GENERAL CHARACTERISTICS
Maximum Display: LCD, 3-1/2 digits (counts up to 1 999)
15 mm (0,6”)
Polarity: Minus displays automatically and plus
superimposes
Measuring Method: Integral dual switch
LCD: 45 mm x 23 mm
Sampling Speed: 2 times per second
Overcharge Indicator: Displays “I”
Operation Environment: 0 ºC – 104 ºF, at < 80% HR
Storage Environment: 14 ºF – 122 ºF, at < 85% HR
Low Battery Indicator: It displays “ ”
Characteristics 3 V Uses 2 Carbon–Zinc, Type AAA,
batteries DC: 1,5 V DC included
Static Electricity: Around 4 mA
Product Dimensions: 160 mm x 76 mm x 32 mm
Product Ney Weight: 155 g (includes battery)
ENGLISH
