TSC Printronix MB340 User Manual

24
5. Thread the media under the damper assembly, through the media sensor and under the printhead. Keep feeding the media
until the media extends out of the front side of the cutter.
6. Align the media with the media guide ensuring that the
media is threaded under the guide.
7. Adjust the media guide ensuring that the location of the
guide fits with the media’s width.
Damper Assembly
Media Sensor
Printhead
