TScale CW Series - BW;CW;VW Parts List

BW / CW/VW/BWS Series Indicator Technical Manual
- 23 -
12.2. BW/CW/VW Parts List
No
Parts Name
Qty
Spec
1
Key Panel
1
2
Display Protection Plate
1
3
Front Cover
1
4
Main PCBA
1
5
Insulation Washer
6
8x3.1x1.5t
6
Self Thread Screw
6
3x10
7
Screw
3
M3x16 (Optional)
8
Insulation Washer
3
8x3.1x1.5t (optional)
9
RS-232 PCBA
1
(0ptional)
10
Seal Ring
1
11
Screw Column
3
5.8x3.8x10H (Optional)
12
Analog Output PCBA
1
13
Nut
3
M3, Hexagon
14
Self Thread Star (+) Screw
2
4x10
15
Washer
2
9x4.4x0.8t
16
Battery bar
1
17
Battery
1
6V/4Ah
18
Spacer
2
(Optional)
19
Back Cover
1
ABS
20
Self Thread Star (+) Screw
6
4x116
21
AC Adaptor Jack
1
22
Air Connecter
1
5Pin For load cell
23
Air Connecter
1
9Pin for Out Put (Optional)
24
D Connecter
1
9 Pin ( Optional0
25
Name plate
1
