Specifications
Body
Clamps
* at a thickness of 2 mm and a width of the knife 15mm.
Desktop domestic device Prole is a universal sharpening device designed for double-sided
sharpening of blades without reinstallation, for forming a symmetrical contour prole of blade,
correction, grinding and polishing the edges of the cutting tools.
4
Point angle depending on the clamping, conguration of the blade
and the abrasive used. (Standard)
Minimum 7 °
Maximum 23 °
Device overall dimensions
(without clips, Stand and abrasive holder) mm.
No more than:
250x220x330
Weight of the K01RP body without main units. 1.68 kg.
Weight of the K03 body without main units. 2,05 kg.
The length of the abrasive holder assembled.
710mm
The length of the abrasive used. Min 150mm.
Max 210mm.
Maximum blade treatment area. 700mm
Angle of the xed rotation of the frame. 180°±0.2°
Deviation of the front (mounting) surface of the frame from the pivot
plane.
±0.2°
Type of clamp Type of blade Minimum angle of the
sharpening for the side
Single clamp Full at grind 11°
Double clamp Full at grind 11°
Single llet clamp Flat, full at grind 7°
Double llet clamp Flat, full at grind 7°
Wholemilled clamp Flat 9°
Doble conical clamp Flat, full at grind 11°
Small universal table Flat, full at grind,
carpenter’s tools
11° to 90°
