TTS TEMPO - Page 5

Selection
Validation
Selection
Validation
▼
▲
■ Select if the traffic is more or less heavy on
this side with + and - (select) user-defined
keys.
■ Validate.
One side heavy traffic programming
LOAD +
LOAD -
Selection
Validation
STEP 3
Traffic programming
■ Select the uneven density of the traffic with
the + and - (select) user-defined keys.
(please refer to the time table page 3)
■ Validate.
▼
▲
HEAVY
VERY HEAVY
LIMIT
Selection
Validation
STEP 4
Roadwork length programming
■ Select the length between the two traffic light
with the + and - (select) user-defined keys.
■ Validate.
You must hear a double BEEP.
Validation
STEP 5
Validation of the cycle on the 2nd traffic light
Traffic light 1
Mode selection
STEP 1
STEP 2
LIGHT: 12,0V
FLASHING M
CYCLE:
UNEVEN
DIRECTION
TRAFFIC:LOAD
UNEVEN
TRAFFIC:HEAVY
UNEVEN
LENGHT:100m
UNEVEN + 12,0V
100m HEAVY m
Traffic light 2
UNEVEN - 12,0V
100m HEAVY a
The traffic load setting is done on the 1st
light:
LOAD + : Light 1- for more dense traffic.
LOAD - : Light 1 - for less dense traffic.
▼
▲
100m
200m
300m
UNBALANCED TRAFFIC PROGRAMMING
5
Traffic is more important
on a traffic axis.
■ Select « Uneven » mode with the + and -
(mode) user-defined keys.
■ Validate.
■ Switch on the remote control
■ Direct it to the window display symbol
You must hear a double BEEP.
■ Go to the 2nd traffic light
■ Direct the remote control to the window
display symbol
■ Validate.
