TuffStuff CDP-300 - Page 28

41
28
41
28
*11
41
28
28
41
*46
28
41
41
28
41
28
41
28
100%
Fully Tighten
Wrench tighten all hardware in this step.
Step 15
Step 15 Assembly List
Item Qty. Description
28 8 HEX HEAD CAP SCREW GR-5 Z/P 1/4-20 X 3/4
41 8 FLAT WASHER USS Z/P 1/4"
*11 1 REAR SHROUD, LEFT SIDE ASSEMBLY
*46 1 REAR SHROUD, RIGHT SIDE ASSEMBLY
Note:
• It is strongly recommended that two people
participate in this assembly step.
• Some parts have been removed for Clarity.
28 CDP-300 Dual Adjustable Pulley System W/150 lbs Weight Stacks
