TuffStuff CDP-300 - Pre-Assembled Components

Pre-Assembled Components
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
*1 REAR UPRIGHT ASSEMBLY 0 UP8071X1 1 *11 REAR SHROUD, LEFT SIDE ASSEMBLY 0 UP8075X1 1
*2 BASE FRAME, LEFT SIDE ASSEMBLY 0 UP8066X1 1 *12 FRONT SHROUD ASSEMBLY 0 UP8076X1 1
*3 BASE FRAME, RIGHT SIDE ASSEMBLY 0 UP8067X1 1 *13 CARRIAGE, LEFT SIDE ASSEMBLY 0 UP7686X1 1
*5 TOP FRAME, LEFT SIDE ASSEMBLY 0 UP8068X1 1 *14 CARRIAGE, RIGHT SIDE ASSEMBLY 0 UP7685X1 1
*6 TOP FRAME, RIGHT SIDE ASSEMBLY 0 UP8069X1 1 *15 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS ASSY BNH1982X3 2
*7 ADJUSTABLE PULLEY BRACKET ASSEMBLY 0 UP8074X1 2 *27 CABLE ASSEMBLY CDP-300 0 UP8078X1 2
*8 CHIN UP CROSS BRACE ASSEMBLY 0 UP8070X1 1 *46 REAR SHROUD, RIGHT SIDE ASSEMBLY 0 UP8075X2 1
*9 ACCESSORY HOLDER TUBE ASSEMBLY 0 UP8077X1 1 *51 10 LB STEEL WEIGHT PLATE BLK 4 9/16 X 9 7/16 ASM BNH1650 28
Parts List
33CDP-300 Dual Adjustable Pulley System W/150 lbs Weight Stacks
