COLOR CHART
*BLACK BOLD = PRE-ASSEMBLED COMPONENTS
CDP-300
BLACK BOLD = SUBASSEMBLY COMPONENTS
Parts List
BLACK = HARDWARE
REV0
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
1 REAR UPRIGHT 0 UP8071 1 57 BUTTON HEAD SOCKET CAP SCREW 10-32 X 1/2 BNH3406 8
2 BASE FRAME, LEFT SIDE 0 UP8066 1 58 BUTTON HEAD SOCKET CAP SCREW B-Z/P 1/4-20 X 1/2 BNH4091 8
3 BASE FRAME, RIGHT SIDE 0 UP8067 1 59 BUTTON HEAD SOCKET CAP SCREW B-Z/P 3/8-16 X 1 3/4 BNH2590 6
4 SELECTOR POST 0 UP8072 2 60 BUTTON HEAD SOCKET CAP SCREW B-Z/P 5/16-18 X 4 BNH4044 6
5 TOP FRAME, LEFT SIDE 0 UP8068 1 61 BUTTON HEAD SOCKET CAP SCREW Z/P 3/8-16 X 3 5/8 BNH3408 2
6 TOP FRAME, RIGHT SIDE 0 UP8069 1 62 FLAT SAE WASHER B-Z/P #12 BNH4008 8
7 ADJUSTABLE PULLEY BRACKET 0 UP8074 2 63 FLAT WASHER SAE Z/P 5/16" BNH2534 12
8 CHIN UP CROSS BRACE 0 UP8070 1 64 CABLE STOPPER SHELL 1 1/2 X 1 3/4 BNH4230 4
9 ACCESSORY HOLDER TUBE 0 UP8077 1 65 7/8 RD X 1 5/8 LINK 1/8 CABLE BNH4231 4
10 GUIDE ROD 0 UP8073 4 66 OVAL HEAD SCREW Z/P #10-32 X 1 1/8 BNH2793 4
11 REAR SHROUD 0 UP8075 2 67 SNAP LINK Z/P 8MM X 80MM BNH0065 6
12 FRONT SHROUD 0 UP8076 1 68 NYLON BUSHING 25/32 ID X 1 1/16 OD X 29/32 BNH0532 64
13 CARRIAGE, LEFT SIDE 0 UP7686 1 69 NYLON INSERT LOCK NUT Z/P 5/16-18 BNH2056 6
14 CARRIAGE, RIGHT SIDE 0 UP7685 1 70 PLASTIC INSERT CAP 2" SQ 10-14 GA BNH0012 4
15 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS ASSY BNH1982 2 71 PLASTIC INSERT CAP 1 1/4" RD V30906 BNH3407 4
16 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 0 UP3035 2 72 PLASTIC INSERT CAP 1" X 3" _ 11 GA BNH0007 2
17 FLAT WASHER Z/P 3/4 X 2 BNH2128 8 73 PLASTIC INSERT CAP 2 X 3 _ 11-14 GA BNH0052 1
18
WEIGHT STACK SPACER 1 1/4 RD X 5 0 UP6745 4 74 PLASTIC INSERT CAP 3" SQ 10-14 GA BNH2992 1
19 RUBBER DONUT 3/4 X 2 1/2 BNH0068 4 75 PLASTIC INSERT CAP ELLIPTICAL 2 X 4 (50MM X 100MM) BNH1794 2
20 BLACK NYLON PULLEY WIDE GROOVE 3/8 X 1 X 3 1/2 BNH2832 14 76 PULL PIN 1/2 X 2 3/4 SHORT NOSE (YELLOW KNOB) BNH0640 2
21 NYLON ANKLE STRAP BNH3203 1 77 ROLL PIN B/O 3/8 X 2 BNH0661 2
22 LOW ROW BAR 1 1/4 ALUMINUM BNH1771 1 78 ROLLER WHEEL BNH2869 6
23 SQUAT BAR 46" DOUBLE LINK (TUBULAR) BNH3228 1 79 RUBBER FOOT FOR 6 X 4 1/4 PLATE BNH1647 3
24 CONTOUR ERGO HANDLE LONG STRAP BNH2738 2 80 SHOULDER BOLT ALLOY 1/2 X 1 1/2 BNH0098 2
25 FLANGED SPACER Z/P 3/8 X 16.5MM BNH4283 4 81 SOCKET SET SCREW Z/P 10-32 X 1/8 BNH2088 2
26 NYLON SPACER 3/8 X 7/8 X 3/8 BNH0392 2 82 SPLIT LOCK WASHER B-Z/P 1/4 BNH2686 8
27 CABLE CDP-300 0 UP8078 2 83 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 4
28 HEX HEAD CAP SCREW GR-5 Z/P 1/4-20 X 3/4 BNH2106 12 84 YELLOW GRIP 1/2 X 4 BNH3059 2
29 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 BNH2037 2 85 TFI EMBLEM 1.88 HIGH X 1.98 WIDE BLUE AND CHROME BNH4304 1
30 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 3/4 BNH2040 6 86 DECAL NUMBERS 10-200 LBS/KGS 7/8 X 3 YELLOW & BLK BNH4069 2
31 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 9/16 BNH4314 12 87 FACILITY SIGN BE ALERT! THE FITNESS EQUIPMENT... BNH3138 1
88 EXCECISE CHART CDP-300 DECAL BNH3149 1
33 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 BNH2045 4 89 LABEL CAUTION CHECK PULL-PIN IS FULLY... 1 1/2 X 1 3/8 BNH2912 2
34 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 BNH2046 3 90 LABEL DANGER CHECK RETAINING NUT... 1.5 X 1 BNH3146 2
35 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3 1/2 BNH2107 2 91 LABEL IMPORTANT FOR SMOOTH PERFORMANCE... BNH2916 2
36 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 4 BNH2267 2 92 LABEL RESISTANCE RATIO AT THE HANDLE 3X6 BNH3150 1
37 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 1 1/2 BNH2171 4 93 LABEL WARNING ANCHOR BOLT, 2 X 1 1/4" BNH3089 3
38 SPLIT LOCK WASHER Z/P 1/2" BNH0572 8 94 LABEL WARNING KEEP BODY, HANDS, 1 1/2 X 2 1/4 BNH2908 2
39 SPLIT LOCK WASHER Z/P 3/8" BNH0658 6 95 LABEL_TFI SERIAL NO. 2.5 X 1.5 BNH3147 1
40 ARC WASHER SAE Z/P 1/2" BNH2697 2 96 LABEL-DANGER DO NOT LEAN AGAINST OR PULL... BNH2955 2
41 FLAT WASHER USS Z/P 1/4" BNH2105 12 97 LABEL-DANGER USE THIS EQUIPMENT ONLY... BNH2903 1
42 FLAT WASHER SAE Z/P 1/2" BNH2031 6 98 LABEL-IMPORTANT ADJUST CABLE TENSION HERE BNH2924 2
43 FLAT WASHER SAE Z/P 3/8" BNH2030 70 99 LABEL-IMPORTANT FOR SMOOTH PERFORMANCE... BNH2925 2
44 NYLON INSERT THIN PATTERN LOCK NUT Z/P 3/8-16 BNH2026 35 100 LABEL-INSPECTIONS RECOMMENDED INSPECTION… BNH3137 1
45 FINISHED HEX NUT Z/P 1/2-13 BNH0206 6 101 LABEL-SCHEDULE REPLACEMENT PARTS... BNH3135 1
47 SWIVEL DOUBLE PULLEY BRACKET 0 UP7688 2 102 LABEL-WARNING KEEP BODY, HANDS... BNH2926 2
48 CARRIAGE COVER PLATE 0 UP6765 2 103 LABEL-WARNING_SERIOUS INJURY OR DEATH BNH3134 1
49 CABLE RETAINER BRACKET (L-SHAPED) 0 UP0014 4 104 LABEL-WARRANTY LIGHT COMMERCIAL BNH3136 1
50 TOP PLATE DOUBLE PULLEY HOLDER 0 UP7689 2 105 SUPER LUBE TEFLON LUBRICANT 82340 BNH0704 1
52 NYLON SNAP-IN FINISHING PLUG 3/8" BNH2280 4 106 HEX KEY 1/8" BNH2541 1
51 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 BNH1237 28 107 HEX KEY 3/16" BNH2542 1
53 1-1/4" RUBBER POLE STORAGE CLIP BNH3243 4 108 HEX KEY 5/32" BNH2545 1
54 2" NYLON PULLEY BNH3084 2 109 HEX KEY ALLOY 1/4" BNH0375 1
55 BLACK NYLON PULLEY WIDE GROOVE 3/8 X 1 X 4 1/2 BNH2834 6 110 HEX KEY ALLOY 3/32" BNH0372 1
56 BRONZE BUSHING SAE .502X.628 X 1/2 X 7/8 X 1/8" BNH0528 4 111 HEX KEY ALLOY 7/32" BNH0575 1
Parts List
32 CDP-300 Dual Adjustable Pulley System W/150 lbs Weight Stacks
www.tuffstuffi tness.com
