TuffStuff CPL-400 - Parts List and Diagrams; Pre-Assembled Component Details

COLOR CHART
*BLACK BOLD = PRE-ASSEMBLED COMPONENTS
CPL-400
BLACK BOLD = SUBASSEMBLY COMPONENTS
Parts List
BLACK = HARDWARE
REV0
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
1 BECH FRAME 0 UP8365 1 36 LABEL-DANGER CHECK RETAINING NUT... 1.5 X 1 BNH3146 1
2 SIDE FRAME 0 UP8366 1 37 LABEL-DANGER USE THIS EQUIPMENT ONLY... BNH2903 1
3 TOP CROSS BRACE 0 UP8367 1 38 LABEL-INSPECTIONS RECOMMENDED INSPECTION… BNH3137 1
4 WEIGHT HOLDER 0 UP8368 1 39 LABEL-SCHEDULE REPLACEMENT PARTS… BNH3135 1
5 SWIVEL FOOT ROLL TUBE 0 UP8369 1 40 LABEL-TFI SERIAL NO. 2.5 X 1.5 BNH3147 1
6 LEFT SIDE UPPER HANDLE 0 UP8370 1 41 LABEL-WARNING KEEP BODY, HANDS, 1 1/2 X 2 1/4 BNH2908 1
7 RIGHT SIDE UPPER HANDLE 0 UP8371 1 42 LABEL-WARNING KEEP BODY, HANDS... 1 1/2 X 2 5/8 BNH2909 1
8 LEFT SIDE LOWER HANDLE 0 UP8372 1 43 LABEL-WARNING_SERIOUS INJURY OR DEATH BNH3134 1
9 RIGHT SIDE LOWER HANDLE 0 UP8373 1 44 LABEL-WARRANTY LIGHT COMMERCIAL BNH3136 1
10 REINFORCEMENT PLATE 1/4 X 2 X 7 (BEND) 0 UP8170 2 45 TFI EMBLEM 1.88 HIGH X 1.98 WIDE BLUE AND CHROME BNH4304 1
11 REINFORCEMENT PLATE 1/4 X 2 X 7 0 UP8374 2 46 ADJUSTABLE CIRCULAR PLATE 0 UP8050 1
12 AXLE 0 UP8375 1 47 PIVOT ARM 0 UP8051 1
13 BACK PAD 0 UP8376 1 48 COVER PULLEY PLATE 0 UP8060 1
14 REAR CROSS BRACE 0 UP8377 1 49 BLACK NYLON PULLEY WIDE GROOVE 3/8 X 1 X 4 1/2 BNH2834 1
15 FOAM FOOT ROLL 2 1/4 X 4 1/4 X 18 W/VINYL 0 UP8378 1 50 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 8
16 CABLE 0 UP8379 1 51 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 1/4 BNH2038 1
17 ALUMINUM WASHER .390 ID X 1.500 OD X .150 THK BNH1541 5 52 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 BNH2041 1
18 PLASTIC HORIZONTAL ELLIPTICAL SHOE W/LOCK BNH3236 4 53 HEX KEY ALLOY 3/32" BNH0372 1
19 FOOT ROLL PLASTIC RING 2" BNH3272 1 54 PLASTIC INSERT CAP 1 1/4" RD V30906 BNH3407 4
20 FOOT ROLL PLASTIC WASHER BNH3273 1 55 PLASTIC INSERT CAP 1 7/8" RD 10-14 GA BNH0003 2
21 BUTTON HEAD SOCKET CAP SCREW Z/P 3/8-16 X 1 BNH2033 6 56 PLASTIC INSERT CAP 2 X 3 _ 11-14 GA BNH0052 3
22 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 2 3/4 BNH2045 2 57 PLASTIC INSERT CAP 2" RD 10-14 GA BNH0004 4
23 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 4 BNH2267 4 58 PLASTIC INSERT CAP 2" SQ 10-14 GA BNH0012 1
24 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 2 BNH3274 1 59 PULL PIN 1/2 X 5 5/8 STIFF SPRING (YELLOW KNOB) BNH4075 1
25 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 3 1/4 BNH4199 4 60 ROD END 1/2-13 BNH1828 1
26 HEX HEAD CAP SCREW GR-5 Z/P 1/2-13 X 5 1/4 BNH2114 4 61 RUBBER BUMPER 3/8 X 2 1/2 BNH0511 1
27 NYLON INSERT JAM LOCK NUT Z/P 3/8-16 BNH2026 4 62 RUBBER GRIP 1.1875 ID X .125 X 8 1/2 BNH1033 4
28 NYLON INSERT LOCK NUT Z/P 1/2-13 BNH2029 8 63 RUBBER WASHER 1 7/8 ID X 3 OD X 19/32 TK BNH1909 1
29 FLAT WASHER SAE Z/P 3/8" BNH2030 12 64 SOCKET SET SCREW Z/P 10-32 X 1/8 BNH2088 1
30 FLAT WASHER SAE Z/P 1/2" BNH2031 16 65 SPACER 10.3 ID X 19.1 OD X 6 MM CHECK DESC BNH4303
31 SPLIT LOCK WASHER Z/P 3/8" BNH2032 7 66 SPLIT BOLT GR-8 Z/P 1/2-13 X 1 (RND CUT) BNH0479 1
32 SPLIT LOCK WASHER Z/P 1/2" BNH0572 2 67 STEEL BUMPER WASHER Z/P 3/8" BNH0498 1
33 HEX KEY ALLOY 7/32" BNH0575 1 68 URETHANE BUMPER 1 3/4 BNH229 1
34 FACILITY SIGN BE ALERT! THE FITNESS EQUIPMENT… BNH3138 1 69 WEIGHT COLLAR 49MM ID X 7/8 X 2 3/4 BNH3403 1
35 LABEL-CAUTION CHECK PULL-PIN IS FULLY... 1 1/2 X 1 3/8 BNH2912 1
Pre-Assembled Components
ITEM DESCRIPTION REV. PART NO. QTY. ITEM DESCRIPTION REV. PART NO. QTY.
*1 BECH FRAME ASSEMBLY 0 UP8365X1 1 *7 RIGHT SIDE UPPER HANDLE ASSEMBLY 0 UP8371X1 1
*2 SIDE FRAME ASSEMBLY 0 UP8366X1 1 *8 LEFT SIDE LOWER HANDLE ASSEMBLY 0 UP8372X1 1
*4 WEIGHT HOLDER ASSEMBLY 0 UP8368X1 1 *9 RIGHT SIDE LOWER HANDLE ASSEMBLY 0 UP8373X1 1
*5 SWIVEL FOOT ROLL TUBE ASSEMBLY 0 UP8369X1 1 *16 CABLE ASSEMBLY 0 UP8379X1 1
*6 LEFT SIDE UPPER HANDLE ASSEMBLY 0 UP8370X1 1
Parts List
19CPL-400 Plate Load Leg Extension/Prone Leg Curl Bench
