TuffStuff CSM-600 - Page 16

16
13
*15
24
*19
24
2
16
*20
*15
24
*19
24
13
2
Step 3
Step 3 Assembly List
Item Qty. Description
13 1 SHAFT RETAINER PLATE
*15 1 PRESS BAR HOUSING RT ASSEMBLY
16 1 LINEAR SHAFT 1 X 69 11/16
*19 1 SAFETY STOPPER BRACKET RT ASSEMBLY
*20 1 WEIGHT LIFT BAR ASSEMBLY
24 2 RUBBER DONUT 1 X 2 1/2
Note:
Some parts have been removed for Clarity.
Note:
It is strongly recommended that two
people participate in this assembly step.
16 CSM-600 Basic Smith Machine/Half Cage Combo w/Safety Stoppers
www.tuffstuftness.com
