Step 6
Step 6 Assembly List
Item Qty. Description
5 1 SELECTOR POST LT
6 1 SELECTOR POST RT
27 4 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 3
35 8 FLAT WASHER SAE Z/P 3/8”
39 4 NYLON INSERT JAM LOCK NUT Z/P 3/8-16
Note:
Position reference numbers facing
toward the inside of the unit.
Note:
Some parts have been removed for Clarity.
Note:
It is strongly recommended that two
people participate in this assembly step.
Loosely Tighten
70%
Loosely Tighten
70%
Loosely tighten all hardware in this step.
DO NOT Fully Tighten. Some component(s)
may need pre-assembly and or alignment
during the assembly process.
