TuffStuff SPT-6 - Page 10

SPT-6 SIX PACK TRAINER
5
48
65
48
5
48
65
5
48
65
48
5
48
65
9
Step 8 LOW ROW CABLE
Assembly List
Item # Description Qty.
4 DOUBLE FLOATING PULLEY BRACKET LT 1
10 LOW ROW CABLE 1 48 FLAT WASHER SAE B/O 1/4” 4 51 HARD PVC CABLE STOPPER 1 1/2 RD X 2 2 53 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 1 3/4 2 64 NYLON D HANDLE 2 65 NYLON INSERT LOCK NUT B/O 1/4-20 2 79 SHOULDER BOLT ALLOY 3/8 X 3/4 2 81 SNAP LINK Z/P 8MM X 80MM 2 86 STRAP BRACKET 20 #SF20 STAINLESS STEEL 2
NOTES: 1. SOME PARTS NOT SHOWN FOR CLARITY
D
C
E
F
STEP 2
A
B
C
STEP 1
