TuffStuff SPT-6 - Page 12

SPT-6 SIX PACK TRAINER
11
52
66
15
59
85
49
49
85
59
52
66
15
59
85
49
49
85
59
Assembly List
Item # Description Qty.
3 BACK PAD FRAME 1
15 SEAT BEARING HOUSING 1
49 FLAT WASHER SAE B/O 3/8” 2
52 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 6 1
59 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 2
66 NYLON INSERT THIN PATTERN LOCK NUT B/O 1/2-13 1
85 SPLIT LOCK WASHER B/O 3/8” 2
Step 10
MAKE SURE SET SCREW ON
ITEM NO. 15 IS ON THIS SIDE
SO IT LINES UP WITH SMALL
NOTCH ON ITEM NO. 11
