SPT-6 SIX PACK TRAINER
67
49
49
56
49
56
68
22
43
84
18
27
7
26
76
76
50
25
50
41
67
49
49
56
49
56
68
22
43
84
18
27
7
26
76
76
50
25
50
41
6
Assembly List
Item # Description Qty.
7 GUIDE ROD 3/4 RD X 67 1/2 2
18 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 1 22 TOP PLATE PULLEY BRACKETS 1 25 WEIGHT STACK SPACER 5” 2 26 10 LB STEEL WEIGHT PLATE BLACK 14 27 10 LB TOP PLATE W/ADJ SLTR BAR 1 41 DECAL-WEIGHT NUMBERS REF TP-10 (150 lbs) 1 43 FINISHED HEX NUT B/O 1/2-13 1 49 FLAT WASHER SAE B/O 3/8” 4 50 FLAT WASHER B/O 3/4 X 2” 4 56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 2 67 NYLON INSERT THIN PATTERN LOCK NUT B/O 3/8-16 2 68 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 2 76 RUBBER DONUT 1 X 2 1/2 4 84 SPLIT LOCK WASHER B/O 1/2” 1
58
49
67
49
58
49
67
49
RAISE AND HOLD GUIDE RODS AND ASSEMBLE HARDWARE AS SHOWN.
Step 5
NOTES: 1. REMOVE WEIGHT SHIELD BEFORE DOING THIS STEP.
