TuffStuff SXT-LP - Step 3 Assembly

Leg Press Option for XT Gym Series www.tu stu tness.com
17
9
9
*4
9 9
*4
Step 3
Step 3 Assembly List
Item # Description Qty.
*4 CARRIAGE 1
9 LINEAR SHAFT 2
Loosely Tighten
70%
Loosely Tighten
Loosely tighten all hardware in this step.
Rear View
Note:
1. Slide linear shaft into carriage.
