Parts Breakdown RTC 12
POSITION PART # DESCRIPTION QTY
1 MTRC400000 “R CLIP 4MM 2
2 MTYT1066010204 HITCH PIN 2
3 MTTX0202 LOWER HITCH BRACKET 2
4 MTTX0203 “U” BOLT, LOWER HITCH BRACKET 2
5 MTNM120000 HEX NUT 12MM 4
6 MTBM101530 BOLT 10 X 30 8
7 MTTX0101 A FRAME 1
8A MTTX030402 SUPPORT-GEARBOX SHEILD 1
8B MTTX030401 GEARBOX SHIELD 1
9 MTBM812516 BOLT 8 X 1.25 X 16 4
10 MTYT1066010202 TOP HITCH PIN 1
12 MTOS356210 OIL SEAL 35.62.10 1
13 MTSRI62000 SNAP RING D.30 INTERNAL 1
14 MTB6007000 BEARING 6007 1
15 MTTX0307 INPUT SHAFT 1
16 MTSRE30000 SNAP RING D.30 EXTERNAL 1
17 MTTX0303 PINION GERA Z-13 1
18 MTB30305 BEARING 30305
19 MTSRI62000 SNAP RING D.62 INTERNAL 1
20 MTTX0309 GEARBOX CAP (DIA 62.) 1
21 MTSRE34000 SNAP RING D.34 EXTERNAL 1
22 MTTX0402 SHIM 2MM 1
23 MTTX0507 GEAR DRIVE 1
25 MTB62072RS BEARING 6207-2RS -
26 MTTX0304-40 DRIVE SHAFT RTC-040 -
MTTX0304-50 DRIVE SHAFT RTC-050 -
MTTX0304-60 DRIVE SHAFT RTC-060 1
27 MTTX0306 GASKET-DRIVE SHAFT 112 X 96 X 9 X 0.5 1
28 MTTX0301-40 DRIVE SHAFT TUBE HOUSING RTC-040 -
MTTX0301-50 DRIVE SHAFT TUBE HOUSING RTC-050 -
MTTX0301-60 DRIVE SHAFT TUBE HOUSING RTC-060 -
29 MTBM101525 BOLT 10 X 25 4
31 MTTX0304 RING GEAR Z19 1
35 MTTX0302 HOUSING-GEAR BOX 1
36 MTYT10660303000 GEARBOX OIL PLUG 1
37 MTOP1212500 OIL PLUG 12 X 1.25 1
38 MTTX0301 LIFTING HOOK 1
41 MTDP1615000V BREATHER CAP M16 X 1.5 VENTED 1
42 MTBM101525 BOLT 10 X 25 2
43 MTYT1066050200 STAND BRACKET 1
Monroe Tuine
RTC 40 - RTC 48 - RTC 60
