ID-Lock Smart Installation guide - Ver. 1.3

26

Step 26

Mount the battery in the battery cabinet as shown here. Note that the battery should slide

into the cabinet with the cable first.

Step 27

Snap the battery cabinet to the Carelock ACE Split unit after attaching the battery

connector.
