ID-Lock Smart Installation guide - Ver. 1.3
27
Additional information
For details about the TM2-box, see separate TM2 Installation- & User Guide.
The TM2-box needs configuration before it is ready to use. The configuration requires an
Android application especially made for that purpose. Please contact the Tunstall office in
Malmö for details about the application.
Tx75 transmitters
There are many different Tx75 transmitters and most of them can be reprogrammed to act
in different ways. The recommended types of transmitters and their IDs for ID-Lock Smart
are:
• K2315-ID4 or K2315-ID2 with IDs between 1 and 927 for residents
• K2315-ID4M with IDs between 928 and 991 for the staff.
Make sure you order the correct transmitters with the correct IDs to save the time to
reprogram them in the field (which requires a special programming box).
IDT zone-IDs
The zone-ID that is transmitted from the IDT is set by dip-switches inside the IDT. There are
10 switches, representing 10 binary bits with the least significant bit to the left (i.e. the
reverse from how a binary number is normally represented in writing).
The zone-ID range that normally should be used for ID-Lock is 768 to 910. Other zones may
cause the Tx75 transmitter to behave in undesired ways.
Tunstall AB
Box 9028 Tel: 040-625 25 00
200 39 Malmö info@tunstallnordic.com
Visiting address: Agnesfridsvägen 113 A www.tunstallnordic.com
