Tunturi B30 - Page 56

56
Cardio Fit B30
1 Main frame 1
2 Front stabilizer 1
3 Rear stabilizer 1
4 End cap for front
stabilizer
2
5 End cap for rear
stabilizer
2
6 Carriage bolt M8*60 4
7 Curved washer Ø8 8
8 Acorn nut M8 4
9 Allen screw M8*16 4
10 Quick release knob 1
11 Left pedal 1
12 Right pedal 1
13 Seat post 1
14 Flat washer Ø17*Ø8 4
15 Spring washer Ø8 3
16 Nylon nut M8 4
17 Seat 1
18 Computer 1
19 Cover for seat post 1
20 Tension knob w / upper
tension cap
1
21 Lower tension cable 1
22 Hand pulse wire 2
23 Grommet 1
24 Handlebar 1
25 Allen screw M8*35 2
26 Allen screw M8*20 1
27 France nut 2
28 Locknut M10 3
29 Bowl shaped spacer 1
30 Sensor wire 1
31 Front post 1
32 Middle sensor wire 1
33 Crank 1
34 Seat post bushing 1
35 Axle for flywheel 1
36 Bearing 6000 3
37 Flywheel 1
38 Copper washer 1
39
L
Chain cover L 1
39
R
Chain cover R 1
40 Self-tapping screw ST5*15 8
41 Self-tapping screw ST5*15 4
42 Belt pulley 1
43 BB assembly 1
44 Magnet assembly 1
45 Plastic spacer 2
46 Locknut M8 1
47 Bolt M8*55 1
48 Belt 1
49 Sensor bracket 1
50 Hex head screw M6*25 1
51 Hex head nut M6 2
52 Spring 1
53 Idler wheel 1
54 Powder spacer 1
55 Spring 1
56 Adjusting nut 1
57 Adjusting bolt 1
58 Crank cover 2
59 Spring clutch 1
60 Small pulley 1
61 Bearing 6900 1
HK Hardware Kit 1
NR Description Specs Qty NR Description Specs Qty
