WT-80
34
No Description Size Qty
1 Base Frame 1
2 Vertical Frame 1
3 Left Base Frame 1
4 Right Base Frame 1
5 Vertical Frame
Diagonal Support
2
6 Main Base 1
7 Seat Main Frame 1
8 Lever Arm 1
9 Weight Post Frame 1
10 Lever Support Tube 2
11 Weight Storage Post 2
12 Seat Adjustment 1
13 Linkage Tube 4
14 Seat Linkage Plate 4
15 Lock Pin 1
16 Seat Support 2
17 Front Stabilizer 1
18 Backrest Support 1
19 Backrest Adjustment
Frame
1
20 Pull Bar 1
21 Connection Plate 1
22 Sliding Block 1
23 Double Head Screw Ø20*260 1
24 Double Head Screw Ø16*252 1
25 Double Head Screw Ø16*210 1
26 Square End Cap 5
27 Round Plug Ø25 3
28 Square Plug 25*25 4
29 Square Plug 38*38 2
30 Square Plug 60*60 5
31 Square Plug 75*75 1
32 Rectangular Plug 60*30 4
33 Rectangular Plug 70*50 6
34 Square Bushing 2
35 Square Buffer 1
36 Handle Grip 1
37 Nylon Locking 6
38 PVC Tube 1
39 Lock Nut M12 31
40 L-Shaped Pin 1
41 Metal Bushing Ø25*Ø12*20 8
42 Metal Bushing Ø25*Ø12*8 4
43 Metal Bushing Ø25*Ø16*20 8
44 Rubber Pad 1
45 Rubber Pad 1
46 Foam Roller Ø23*4*540 2
47 Foam Roller Ø30*3*600 1
48 Bearing 6004 2
49 Olympic Sleeve 6
50 Pull Pin 1
51 Long Pull Pin 1
52 Ball Head Pull Pin 1
53 Seat Cushion 1
54 Backrest Cushion 1
55 Cross Recessed
Head Screw
M10*20 1
56 Hex Bolt M10*25 5
57 Hex Bolt M10*40 2
58 Hex Bolt M10*45 4
59 Hex Bolt M12*20 2
60 Hex Bolt M12*63 2
61 Hex Bolt M12*70 2
62 Hex Bolt M12*85 4
63 Hex Bolt M12*95 2
64 Hex Bolt M12*100 2
65 Hex Bolt M12*103 1
66 Hex Bolt M12*105 2
67 Hex Bolt M12*165 1
68 Hex Bolt M12*178 2
69 Washer Ø10 11
70 Washer Ø12 50
71 Big Washer Ø12 1
72 Cone End Locking
Screw
6
Parts list
Teileliste
Liste des pièces
Onderdelen lijst
Lista de piezas
