Electric Specifications
Electric Power
24 VDC– 25W
Selectable Output Voltage
24 Vdc
Maximum Load 25 W.
Inputs And Outputs Galvanically Insulated
Enable contact (remote cleaning enable).
Fan contact (post-cleaning).
4 – 20mA (dP remote reading).
The solenoid valves connected to the unit are normally closed.
The activation of a solenoid valves causes them to open and let out a jet of air.
Alarm Relays
The three alarm relays contain 2 clean contacts on terminals 4 ÷ 9 di J4.
Maximum permitted load: 2A @ 24Vdc
Fuse
1 x 3 A @ 24Vdc.
Working Temperature
from -10°C to 55°C
Storage Temperature
-20°C to 60°C
Timer Specifications:
Pulse Time (Valve Opening)
from 50 ms to 5 sec
Pause Time (Interval Between Valve Openings)
1 sec - 999 sec
Differential Pressure Gauge
Measurable pressure range: from 0 to 4 kPa
Maximum applicable pressure: 16 kPa - 0.16 bar
(optional sensor 10kPa)
War nin g ! Hi ghe r p r es su r es w il l
da m age t he devic e.
Do no t c o nnec t c l og gi n g
measur i ng t ub e s to t h e
compr e s s e d air c irc ui t .
War nin g ! Read t he s ect i on on
in s tal l a ti on be fo re con n ec ti ng
the dev i c e .
