turbofan E22M3 User Manual

Replacement Parts List
13
Item Description E22 E23 E27M2 / E27M3 E28
232765 Oven Element, 1500W, 110 - 120V

232766 Oven Element, 2000W, 230 - 240V

234088
Oven Element, 2800W, 230 - 240V

 M2 only

234089
Oven Element, 2800W, 208 - 220V

 M2 only

234107
Oven Element, 4500W, 208 - 220V  M3 only
234108
Oven Element, 4500W, 230 - 240V  M3 only
025387 Fan Motor, 110 - 120V

013431K Fan Motor, 50 / 60Hz, 208 - 240V

235585 Fan Motor Kit, 129W, 208 - 240V, 50 / 60Hz
  
024503 Motor Timer, 230V
  
024562 Relay, 25A

024505 Relay, 30A
 
234802 Fuse Holder  M3 only

234803 Fuse 10A, 250V  M3 only

234821 Overtemp, 355°C / 670°F - 20k
  
233573 Overtemp Cap
  
233607 Thermostat, 50 - 260°C / 150 - 500°F
   
233887 Rotary ON / OFF Switch
   
233616 Knob Thermostat, 50 - 260°C
   
233617 Knob Thermostat, 150 - 500°F
   
233862 Door Microswitch
   
234251 Capacitor 5uF
  
234136 LED Indicator, 110 - 250V
   
011760 Bake Timer 60 Minute
   
233613 Knob Bake Timer (0 - 60 Minute)
   
015822K Buzzer, 110 - 120V

011794K Buzzer, 208 - 240V
   
233115 Oven Lamp Lens
  
233884 Lamp Bulb G9 25W, 120V Halogen
  
231814 Lamp Bulb G9 25W, 230V Halogen
  
233370 Door Inner Glass - E22

233913 Door Inner Glass - E23

233368 Door Inner Glass - E27

233346 Door Inner Glass - E28

234602 Door Inner Glass Catch
   
233292 Door Hinge - E22

233293 Door Hinge - E23

233294 Door Hinge - E27

233295 Door Hinge - E28

234465 Door Seal - E22

232667 Door Seal - E23

232666 Door Seal - E27M2 / E27M3

234466 Door Seal E28

232379 Leg Adjustable (73 - 80 mm)
   
233883 Oven Lamp Seal
  
When ordering replacement parts, please quote the part number and the description as listed below. If the part required
is not listed below, request the part by description and quote model number and serial number which is shown on the
Technical Data Plate.
Important:
Only genuine authorized replacement parts should be used for the servicing and repair of this oven. The instructions
supplied with the parts should be followed when replacing components.
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer.
