Turbosound Flex Array TFA-600H User Manual

user manual
FLEX ARRAY
FLEX ARRAY user manual
Page 79
TFA-600HDP
TFA-600LDP
TSW-218DP
Dimensions
mm (inches)
710 x 304 x 560
(28” x 12” x 22”)
574 x 710 x 848
(22.6” x 28” x 33.4”)
574 x 1400 x 770
(22.6” x 55.1” x 30.3”)
Net weight
43kg (94.6lbs)
75kg (165lbs)
113kg (248.6lbs)
Frequency range
90Hz – 18kHz ±3dB
80Hz – 20kHz ±10dB
38Hz – 150Hz ±3dB
30Hz – 150Hz ±10dB
35Hz – 150Hz ±4dB
Max SPL (max/cont)
130dB/136dB
133dB/139dB
136dB/142dB
Construction
15mm birch ply
15mm birch ply
18mm birch ply
AMPLIFIER
Type
Class D inc. SMPA and
networked DSP
Class D inc. SMPA and
networked DSP
Class D inc. SMPA and
networked DSP
Power Output
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
2500 watts @ 8 ohms
(1kHz, 0.01% THD)
Dynamic Range
110dB
110dB
110dB
Input Clip
10dBu
10dBu
10dBu
Bandwidth
20Hz – 20kHz ±0.5dB
20Hz – 20kHz ±0.5dB
20Hz – 20kHz ±0.5dB
Power Requirements
100V to 240V AC @50/60Hz
100V to 240V AC @50/60Hz
100V to 240V AC @50/60Hz
Connectors
1 x XLR female input
1 x XLR male link
wired pin 2 hot
1 x XLR female input
1 x XLR male link
wired pin 2 hot
1 x XLR female input
1 x XLR male link
wired pin 2 hot
