Turbosound iQ Series User Manual

16 iQ Series Quick Start Guide 17
Technical Speci cations
iQ8 iQ10 iQ12
System
Frequency response
60 Hz – 18 kHz ±3 dB
55 Hz – 20 kHz -10 dB
55 Hz – 18 kHz ±3 dB
50 Hz – 20 kHz -10 dB
52 Hz – 18 kHz ±3 dB
45 Hz – 20 kHz -10 dB
Nominal dispersion 90° H x 90° V @ -6 dB points 90° H x 60° V @ -6 dB points 80° H x 60° V @ -6 dB points
Maximum SPL 128 dB peak 129 dB peak 130 dB peak
Crossover type Active Active Active
Transducers
1 x 8" (208 mm) LF driver
1 x 1" (25.4 mm)
HF compression driver
1 x 10" (256 mm) LF driver
1 x 1" (25.4 mm)
HF compression driver
1 x 12" (308.5 mm) LF driver
1 x 1" (25.4 mm)
HF compression driver
Limiter
Independent HF, LF,
peak and rms
Independent HF, LF,
peak and rms
Independent HF, LF,
peak and rms
Ampli er
Maximum output power* 2,500 W 2,500 W 2,500 W
Type Class-D Class-D Class-D
Protection Short circuit, open circuit, thermal Short circuit, open circuit, thermal Short circuit, open circuit, thermal
Connectors
Input A / B 2 x combo jack/XLR 2 x combo jack/XLR 2 x combo jack/XLR
Sensitivity Line +4 dBu, mic -22 dBu, switchable Line +4 dBu, mic -22 dBu, switchable Line +4 dBu, mic -22 dBu, switchable
Input impedance 20 k unbalanced, 40 k balanced 20 k unbalanced, 40 k balanced 20 k unbalanced, 40 k balanced
Maximum input level +21 dBu +21 dBu +21 dBu
Output A / B 2 x XLR Linked to input 2 x XLR Linked to input 2 x XLR Linked to input
Mix output XLR, balanced XLR, balanced XLR, balanced
Output impedance 100  unbalanced, 200  balanced 100  unbalanced, 200  balanced 100  unbalanced, 200  balanced
Ultranet input/link 2 x RJ45 2 x RJ45 2 x RJ45
Mains Supply Neutrik powerCON input 20A and link 15A Neutrik powerCON input 20A and link 15A Neutrik powerCON input 20A and link 15A
Controls
DSP
Rotary push-encoder
Buttons for PROCESS, SETUP, EXIT, ENTER
Rotary push-encoder
Buttons for PROCESS, SETUP, EXIT, ENTER
Rotary push-encoder
Buttons for PROCESS, SETUP, EXIT, ENTER
Mixer section
2 x gain controls
(channels A and B)
2 x Line/Mic switch
2 x gain controls
(channels A and B)
2 x Line/Mic switch
2 x gain controls
(channels A and B)
2 x Line/Mic switch
User DSP Functions
Factory EQ presets
Positioning, Sound mode,
Sound Modeling, FBQ
Positioning, Sound mode,
Sound Modeling, FBQ
Positioning, Sound mode,
Sound Modeling, FBQ
Display LCD 128 x 32, blue backlit LCD 128 x 32, blue backlit LCD 128 x 32, blue backlit
Delay 0 - 300 ms 0 - 300 ms 0 - 300 ms
Equalisation
High and low shelving EQ
2 x parametric EQ
High and low shelving EQ
2 x parametric EQ
High and low shelving EQ
2 x parametric EQ
Limiter Zero attack input limiter Zero attack input limiter Zero attack input limiter
Presets 20 total presets, 19 user-de nable 20 total presets, 19 user-de nable 20 total presets, 19 user-de nable
Crossover High Pass L-R 24 dB/oct High Pass L-R 24 dB/oct High Pass L-R 24 dB/oct
Protection Lock-out function for all settings Lock-out function for all settings Lock-out function for all settings
iQ8 iQ10 iQ12
Ultranet Digital Network
System
Signal
Latency
16 channels
< 0.9 ms
16 channels
< 0.9 ms
16 channels
< 0.9 ms
Cabling
Cables
Cable length
Shielded CAT5
max. 246 ft / 75 m recommended
Shielded CAT5
max. 246 ft / 75 m recommended
Shielded CAT5
max. 246 ft / 75 m recommended
Power Supply
Power consumption 150 W @

⁄

max power 150 W @

⁄

max power 150 W @

⁄

max power
Voltage (fuses)
USA / Canada 120 V~, 60 Hz (T 15 A H 250 V) 120 V~, 60 Hz (T 15 A H 250 V) 120 V~, 60 Hz (T 15 A H 250 V)
UK / Australia / Europe
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
Korea / China
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
220-240 V~, 50/60 Hz
(T 10 A H 250 V)
Japan 100 V~, 50/60 Hz (T 15 A H 250 V) 100 V~, 50/60 Hz (T 15 A H 250 V) 100 V~, 50/60 Hz (T 15 A H 250 V)
Enclosure
Dimensions HWD
457 x 279 x 279 mm
(18.0x 11.0 x 11.0")
526 x 324 x 316 mm
(20.7x 12.7 x 12.4")
609 x 370 x 370 mm
(24.0x 14.5 x 14.5")
Net weight 14.7 kg (32 lbs) 17.2 kg (38 lbs) 21.1 kg (46 lbs)
Construction
Injection-moulded
polypropyleneenclosure
Injection-moulded
polypropyleneenclosure
Injection-moulded
polypropyleneenclosure
Finish Black painted Black painted Black painted
Grille Powder coated perforated steel Powder coated perforated steel Powder coated perforated steel
Flying hardware M10 x 3 points M10 x 3 points M10 x 3 points
Accessories
IQ8-WB Steel wall bracket IQ10-WB Steel wall bracket IQ12-WB Steel wall bracket

Turbosound iQ Series Specifications

General

Type	Active Loudspeaker
DSP	Yes
Inputs	XLR
Outputs	XLR
LF Driver	12" Woofer
Coverage Pattern	90° x 60°
Presets	Yes
